PD series distribution boxes provide power distribution for power or lighting loads in various areas of the ship. The installation method can be divided into wall-mounted and embedded according to the size of the capacity. The protection level can reach IP44 according to different.
UsageUses:
PD series marine distribution box is suitable for infrequent operation in the marine electrical network below AC380V / 50Hz or AC440V / 60Hz and below DC 220V It is used for lighting and power distribution, and it is used for overload and short-circuit protection of the controlled distribution lines. The product conforms to the technical standard of CB/T1046-92 "Marine Distribution Box" and the requirements for structural performance in GB/T104 6 standard.
Structural FeaturesFeatures:
This series of distribution boxes are made of high-quality cold-rolled steel plates with a thickness of 1.5mm or more. The inner and outer surfaces are orange-shaped matt spray, and the color can be selected by the user according to the GB3181-82 standard color card.
Protection level IP22 or IP56.
Box body. A single box door is set on the upper part, the box door is embedded with a sealed anti-vibration rubber, the opening angle of the box door is greater than 90 degrees, and it is equipped with a self-elastic door stopper. The door hinge is concealed, and the door lock is anti-seismic The lock buckle and the switch operation plane in the box are provided with protective cover plates, and corresponding switch shunt nameplates are provided. Box mounting feet are detachable mounting feet in line with international standards. The nameplate is made of PVC two-color flame retarding plastic or stainless steel or copper.
